The DM-8208 Digital Matrix System is designed to be flexible, powerful and easy to configure, install and manage. With audio quality tailored for a wide range of applications including background/foreground and paging, the DM-8208 Digital Matrix System provides complete control over audio configuration and signal processing. Basic user controls such as volume and source selection within a zone can be easily operated via the wall-mounted DM-P8208 panel controller. More advanced users requiring multiple zone control can use the Graphical User Interface (GUI) for PC or smart devices. The DM-C8208 can be controlled via Ethernet for easy integration with a wide range of building management and control systems. With the DM-S8208 remote paging station, users can select parts of the desired zone or the entire area to broadcast live calls and local music sources.
DM-C8208
FBT 8x8 Digital Matrix With Powerful DSP
The new FBT DMC-8208 provides an extremely powerful and versatile solution for distributing audio to complex system setups. Allows the user a simple method for switching audio with the 8x8 matrix.
SKU: 45808
HS Code: 85185000
Country of Origin: Korea, Democratic Peoples Republic Of
PRODUCT DESCRIPTION
KEY FEATURES
- Multi-purpose 8-channel DSP matrix controller for simple day-to-day management
- Flexible, customised remote control via PC, smartphone or wall panel using GPIO
- Eight balanced mic/line inputs with Phantom power
- Priority paging features available when using Code DM-S8208
SPECIFICATIONS
Power Consumption:
45w
S/N Ratio:
>80 dN
Controls:
Software/App
Power Supply:
100 - 240V (50Hz - 60 Hz) 24VDC
Freq. Response:
20 - 20,000 Hz
Weight:
3.5 kg
Output:
8x Line
Dimensions (WxHxD):
482 x 44 x 300
Inputs:
8x Mic/Line
DOWNLOADS
PACKING INFO
| SKU | 45808 |
| Outer Carton Quantity | 1 |
| Commodity Code | 85185000 |
| Country of Origin | Korea, Democratic Peoples Republic Of |
